Ultrapure Water Systems(UL)

Small-Footprint EDI Module for High-Purity Water Treatment

Advanced water purification technology designed for industrial and commercial applications. Our systems deliver exceptional performance with energy-efficient operation and minimal maintenance requirements.

Energy Efficient Design
24/7 Technical Support
Low Maintenance
15+ Years Experience
One-Stop Solutions
ISO 9001 Certified

Water Treatment Product Description

Electrodeionization Purified Water 3000lph EDI Ultra Pure Water Machine





What Is Ultrapure Water?

  • Ultrapure Water is a type of highly purified water with a purity far higher than that of ordinary distilled or deionized water.
  • Extremely low conductivity/high resistivity: Resistivity 18.2MΩ•cm (25°C), conductivity 0.06μS/cm, as it contains virtually no conductive ions (such as Nat, Cl-, etc.)
  • Impurity-free: All minerals, organic matter (TOC <1ppb), microorganisms (bacteria/endotoxins), particles (filtered to below 0.2μm), and dissolved gases (such as CO₂, O₂) are removed



EDI Module Feed Water Requirements – RO Water

     Inlet Requirements                                                                                RO Water

  • Feedwater conductivity equivalent (with CO2*) ——————- < 40μS/cm
  • Silica dioxide ———————————————————- < 1ppm (as Si0₂)
  • Iron, Manganese, Sulfides ——————————————– < 0.01ppm
  • Residual chlorine —————————————————— < L0.02ppm (as C1₂)
  • Total hardness ——————————————————— < 1.0pp (as CaC0₃)
  • TOC ——————————————————————— < 0.5ppm (as C)
  • Operating pH range ————————————————— 4-11
  • Operating temperature ———————————————– 41-113℉(5-45°C)
  • Inlet pressure ———————————————————- < 100psi (7bar)





Thank you so much for your valuable time. If you have any questions, please click “Contact Now” to send us an inquiry! Contact Us

Product Specifications

Comprehensive technical details and specifications

Model
UL-EDI-3T
Capacity
3T/H
Product Water
Ultrapure Water
Membrane
EDI: OC-LX-300
Control Type
Ultrapure Water Conductivity Meter
Voltage
220V/380V/50Hz/60Hz.1P
Valve
Automatic
Raw Water Source
Well Water, Tap Water, Seawater, Salt Water, Brackish Water
Rejection
99% ; Resistivity >15 MΩ•cm
Recovery
90-95%

Our Manufacturing Factory

Our factory covers an area of over 10,000 square meters, equipped with advanced manufacturing capabilities and quality control systems.

Why Choose Aomi For Water Treatment?

15 years of expertise delivering world-class water purification solutions

Superior Quality Products

We offer top-of-the-line water treatment systems, including sea water desalination systems industrial reverse osmosis systems, industrial ultrafiltration systems, and EDI Electrodeionization systems

Tailored Water Solutions

Our engineering team will analyze your water usage issues and provide the best solutions to meet your specific industry requirements.To get more information about water treatment machine, please contact with us.

15 years Industry Expertise

With years of experience in the water treatment industry, we have gained extensive knowledge and expertise in various sectors. Our solutions are designed to comply with industry standards and regulations

Premium Quality Related Products

Advanced water purification system designed for industrial applications with cutting-edge technology and reliable performance.

1TPH Seawater Desalination Water Treatment Plant Industrial Use

SWRO-1T-A1-PLC

Seawater Desalination Water Treatment Plant: Reliable Water Solutions  Seawater Desalination Water Treatment Plant provides an…

View Details

35TPH Reverse Osmosis Recycling Water Treatment System

SRO-35T-A4-PLC

Shrimp Farm Recycling Water Treatment Project Case 35tph Reverse Osmosis Recycling Water Treatment System is…

View Details

1T/H Solar Water Treatment System for Sustainable Solution

BWRO-1T-A2-SOLAR

Solar Water Treatment System Sustainable: Clean Water with Renewable Energy Ensuring access to clean, safe…

View Details

Get Your Custom Water Treatment Solution

Tell us about your water treatment needs and our experts will design the perfect system for your application.

Sending your inquiry...

By submitting this form, you agree to our privacy policy. We'll only use your information to provide water treatment solutions and support.

Frequently Asked Questions

Our water treatment solutions are designed to meet the highest industry standards, ensuring reliable, safe, and efficient purification for a wide range of applications, from industrial to commercial and residential needs.

?
When does the warranty period begin?

One year from the date of shipment.

?
Do you have certificates of qualification? What certificates do they have?

Yes, our products have CE and ISO certificates.

?
What is TDS?

Tds stands for total dissolved solids and represents the total concentration of dissolved substances in water.

?
What is the percentage of pure water and wastewater?

It depends on the machine's capacity. Normally, it is 30%-65%. The bigger the capacity, the higher the water recovery.

?
I come from South America. The voltage is 220V, 1-phase, 60Hz, or 440V, 3-phase, 60Hz. Can you accommodate this?

Yes, we can accommodate that. However, the production time will need to be extended to 30 working days. Additionally, the cost will increase by 20-30%, depending on the system capacity.

?
I want to treat well water for direct drinking. What data do I need to provide to help you design a water treatment plant?

Please provide the following information: What is the capacity (liters per hour), or how many people will be using the system? It would be helpful to send us the well water quality analysis report. What is the local voltage?
